Marine Grade Anti-Corrosion Fixed Mini IR Camera

Marine Grade Anti-Corrosion Fixed Mini IR Camera: A Comprehensive Overview

The Marine Grade Anti-Corrosion Fixed Mini IR Camera is a compact yet robust solution specifically engineered for demanding marine environments. Certified with DNV ATEX standards, this camera offers exceptional durability and advanced features tailored for ships and offshore applications.

Features and Specifications

1. Construction and Durability
   Built with stainless steel 316L and finished with a powder coating, this camera is designed to withstand harsh marine conditions. It resists corrosion caused by saltwater exposure, ensuring a long lifespan in marine settings.
2. Advanced Certifications
   The camera holds DNV ATEX certifications, verifying its explosionproof qualities and adherence to safety standards for hazardous environments. This makes it suitable for oil rigs, chemical tankers, and areas requiring stringent safety protocols.
3. Imaging and Performance
   Equipped with IR capabilities, it delivers clear footage even in low-light conditions. Its fixed lens options (2.8mm or 4mm) provide a reliable field of view, perfect for monitoring specific areas on a ship or offshore platform.
4. Weather and Vibration Resistance
   Rated IP68, the camera can operate in extreme temperatures ranging from -40°C to +60°C and withstand vibrations up to 0.7g, making it ideal for vessels constantly in motion.
5. Connectivity and Features
   Supporting PoE and DC12V power options, this camera integrates seamlessly into existing systems. Additional features like WDR, HLC, motion detection, and intrusion detection enhance its usability in security setups.

Applications

1. Marine Vessels
   This camera ensures robust monitoring aboard ships, including cargo vessels, passenger ferries, and oil tankers. Its anti-corrosion and explosionproof qualities are ideal for engine rooms, decks, and cargo holds.
2. Offshore Platforms
   In the oil and gas industry, the camera provides critical surveillance in high-risk zones. Its ability to operate under extreme conditions ensures uninterrupted security and operational monitoring.
3. Port and Dock Security
   With its advanced features, the camera can be deployed for monitoring port facilities, preventing unauthorized access, and ensuring the safety of cargo operations.
4. Specialty Uses
   Industries requiring explosionproof equipment, such as chemical processing or hazardous materials handling, can also benefit from this camera's unique features

Why Choose This Camera?

This camera offers unparalleled reliability for marine applications. Its compact size, coupled with advanced imaging features and rugged construction, makes it a perfect fit for challenging environments. Whether monitoring a ship's operations or safeguarding an offshore platform, it delivers peace of mind with superior performance and durability.

For more details, visit the product page

• Type: KDM— EX— FL***IR03
• Certificates: DNV TA/ATEX/CE/FCC
• Material: Stainless Steel 316L
• Ex Mark: Ex II 2G Ex db op is IIC T6 Gb/II 2D Ex tb op is IIIC T80°C Db IP68
• Protection Class: IP68
• Temp.Range Min: –40°C
• Temp.Range Max: +60°C
• Vibration(0-100Hz): 0.7g
• Video: IP
• Operational Areas: Outdoor
• Mounting: Wall mounted
• IR: Support
• Surface : powder coating
• Resolution: 2MP.4MP etc
• Lens: 2.8mm .4mm etc
• CCTV Add-On: Motion Detection Mask Alarm IP address conflict etc
• Voltage: PoE/DC12V
• Net Weight: 1.65kg
• Dimensions: Width: 98 mm, Depth: 158 mm, Height: 113 mm
