| Camera Parameters | Sensor Type | 1/2.8" Progressive Scan CMOS |
| Minimum Illumination | Color: 0.001 Lux @ (F1.69, AGC ON); B/W: 0.0005 Lux @ (F1.69, AGC ON) |
| Electronic Shutter | 1/25 sec to 1/100,000 sec; slow shutter supported |
| Day/Night Mode | Automatic ICR infrared filter |
| Lens Parameters | Focal Length | 5.5–110 mm, 20x optical zoom |
| Iris | F1.69 – F3.72 |
| Field of View | 45° – 3° (wide to tele) |
| Focus Distance | 100 mm – 1500 mm |
| Zoom Speed | ~3 seconds |
| Compression | Video Compression | H.265 / H.264 |
| H.265 Profile | Main Profile |
| H.264 Profile | Baseline / Main / High |
| Video Bitrate | 32 Kbps – 16 Mbps |
| Audio Compression | G.711a / G.711u / G.722.1 / G.726 / MP2L2 / AAC / PCM |
| Audio Bitrate | Various (16 Kbps – 192 Kbps depending on codec) |
| Video Settings | Main Stream | 1080p up to 30fps |
| Sub Stream | 704×576 up to 30fps |
| Image Adjustment | Brightness, contrast, saturation, sharpness adjustable |
| Exposure Modes | Auto / manual / shutter priority / aperture priority |
| Advanced Features | Focus Mode | Auto / manual / semi-auto |
| Defog | Supported |
| 3D Noise Reduction | Supported |
| ROI | Supports multiple regions |
| Memory Function | Supported |
| Protocols | ONVIF (Profile S, Profile G) |
| Interface Protocols | TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, SMTP, SNMP, IPv6 |
| Network Storage | NAS (NFS, SMB/CIFS), Micro SD (up to 256GB), USB extension |
| General | Material | Stainless steel / titanium alloy |
| Depth Rating | 0 – 300 meters |
| Power Supply | DC 24V |
| Operating Temperature | -40°C to +60°C |
| Dimensions | Approx. 195 × 360 mm (connector excluded) |
| Weight | Approx. 21 kg |
| Package Customization | Supported |
| Accessories | Included Items | Cable, adapter, warranty card, certificate, test report |
| Sensors | Temperature, pressure, etc. |
| Control | Display control terminal |
